Working size: 920(1224）x 2200（2800mm）
Speed: 200-300sheets/min
Designed according to high request and for reliable functon, the operation of the machine is humanized, which can accomplish the setting. revision, implement replacing and memory function in a short time with a exact date displayed.
All the driving rollers adopt the high quality steel with hard chromium plated and the surface is polished
The driving gears adopt high quality alloy steel which is heat treated and polished
With auomatic circulate lubrication and balance device of lubricate oil. the oil level in each unit can be kept even
We can adjust the phase by inputting the data on the touch screen. It has the function of automatic zero return and"Memories
The lead edge feeding and kick feeding are optional
The speed of main motor is adjusted by frequency converter
Gluer
Glue Applicator Wheel RMP synchronized with Folding Belts
Volume of glue application suits for speed of main unit.
Nozzle type Glue Applicator optional (Length and position of Glue Application automatically adjustable)
Folder
High-pressure air blower equipped to get rid of wasted scraps existing at Glue Flaps.
Folding Belts, assisted by vacuum suction, achieve reliable transfer of folding cartons
Hydraulic control of tension of folding belts, released after machine stops, eliminating belts worn-out
Folding Guiding Wheels equipped at end of folder, achieve precise folding
Both bottom Folding Belts driven by servo motors independently, greatly reducing big tolerance happened in process of transfer
Stacker
Pressurized Rollers equipped after folding to force forming of glued &folded cartons pressure motorized adjustable
Mechanical organizer pads glued & folded cartons to achieve more precise folding
Counter&Ejector
Up loading & counting, avoiding glued area dislocated
Servo driven stacking fork, precise & reliable
Timing driven conveyor, neat&tidy
Ejector equipped with vacuum air blower, press cartons down&neatly.
Operation & Control
HMI control operation
Servo Driven, synchronous
